IP Camera 05 - People Counting / Space Occupancy
IP camera with dual sensor for real-time people counting, where entries and exits in specific access / circulation areas are controlled, managing the occupancy of the space. This camera can be installed in indoor and outdoor environments.
RefASTPCC05
IP Camera 05 enables the counting of people entering and leaving access areas, allowing the occupancy of people in those specific locations, including outdoor areas, to be controlled. There is a major concern in controlling the flow of people and the occupancy of spaces according to their size.
Through this camera, together with the access.track software - people counting module, it is possible to control, in a very simple and effective way, spaces such as: shops, shopping centres, supermarkets, museums, event venues, business centres, theme parks, zoos, event parks, etc.
- Image sensor: 1/2.8" Progressive Scan CMOS
- Maximum resolution: 1920 x 1080
- Main stream rate: 1920 x 1080 (1 - 30 FPS)
- Compression: H.265+ / H.265 / H.264+ / H.264
- Bit rate: 32 Kbps - 16 Mbps
- Communication interface: 1 x Ethernet 10/100M BaseT
- Day / Night: Auto / Programmable / Manual
- Installation: Installation height: 2.1 m - Detection area: 1.02 m
- Installation: IH: 2.6 m - DA: 2.3 m | IH: 3.1 m - DA: 3.58 m
- Installation: IH: 3.6 m - DA: 4.86 m | IH: 4.1 m - DA: 5.5 m
- Installation: IH: 4.6 m - DA: 6.14 m | IH: 5.1 m - DA: 6.45 m
- Installation: IH: 5.6 m - DA: 7.40 m | IH: 6.0 m - DA: 8.16 m
- People counting: Access to configuration, real-time control
- Application environment: Outdoor
- Functions: HLC, BLC, 3D DNR
- Alarms: 1 input / 1 output
- Infrared IR: 6 metres
- Audio: Built-in microphone
- Lens: 2 mm (H: 104.5º, V: 70.5º)
- Interoperability: ONVIF
- Power supply: DC12 V / 600 mA, PoE IEEE802.3af
- Protection rating: IP67 (IEC 60529-2013)
- Operating temperature: -30 ºC ~ +60 ºC
- Dimensions: 61 x 168 x 36 mm
- Base dimensions: 152 x 69 mm / 4 screws
- Weight: 435 g
