RGB 8L P8 LED Display Panel
Informative RGB LED panel prepared for outdoor and indoor environments. Possibility of various sizes and resolutions. Used for space occupancy systems, people counting systems, corporate TV systems, car park information systems, etc.
RefQMPP801
The QMPP801 LED panel is an informative display prepared to be installed in indoor and outdoor environments. This panel can be installed vertically or horizontally, allowing the type of information to be displayed to be customised.
This panel is integrated with the people counting system of the access.track solution, displays the occupancy status of the space, the corporate TV of the q.track solution, information from access.track car parks, among other purposes.
- Power supply: 230V
- Screen: 768 x 1024 mm (W x H), Other size (Optional)
- Pitch: 8mm, 5mm (optional) - distance between pixels
- Matrices: SMD RGB LED matrix for outdoor use
- Lines: Allows up to 8 lines with characters 112mm high
- Material: Lacquered aluminium box
- Mounting type: Vertical or horizontal, fixing nuts on the sides and/or bottom
- Application environment: Indoor or Outdoor
- Communication: TCP-IP
- Resolution: 86 x 128 pixel
- Maximum consumption: 800W-P8
- Controller: 1
- Operating temperature: -10ºC to 50 ºC
- Colour: Black, Other (Optional)
- Weight: 17 KG
- Box dimensions: 808 x 1064 x 100mm
- Optional: Custom LED panels with various dimensions, Pitch, resolution, etc.
